CHIN NAN’s Straight SMA Plug to SMT Jack adapters provide a precision solution for bridging standard coaxial test cables to PCB layouts. Seamlessly combining SMA threaded stability with SMT miniaturization, this adapter maintains exceptional impedance continuity from external test equipment to the PCB surface. Operating reliably up to 6 GHz, it is the ideal bridge for microwave module development and high-density RF circuit testing.

Key Features

• Board-Level Test Optimization: Perfectly bridges standard SMA cables to SMT board interfaces to maintain superior impedance matching across transitions.
• Exceptional Broadband Performance: Reliably supports high-frequency transmission up to 6 GHz to meet the rigorous bandwidth standards of 5G, satellite, and high-speed data systems.
• Precision Signal Integrity: Strict 50 Ω impedance control and Low VSWR design significantly reduce high-frequency reflection loss and interference.
• Rugged Threaded Coupling: The standard SMA threaded interface provides excellent mechanical retention for stable electrical contact during frequent testing and vibration.
• High-Density Integration: The compact structure enables engineers to efficiently route high-performance RF signals into confined PCB spaces, maximizing overall test efficiency.
